HL-4GXV-F GPON ONT
GPON ONT with 4x Gigabit LAN ports, WI-FI 6 (AX1800), 2×2 2.4GHz and 2×2 5GHz, 1x VoIP FXS port, mode button
- UK & Ireland stock and lead times
- Demo & loan units, plus rent-vs-buy options
- Engineer-led pre-sales and on-site support
Request the datasheet → · Optical Networking, DCI & Transceivers
Overview
GPON Optical Network Termination products are designed for operators and service providers who seek advantage from the expanded capacity of a fiber access network.
HALNy HL-4GXV-F is a Premium GPON ONT that acts as GPON Home Gateway Unit and is designed to provide affordable access to FTTH networks. The products use a single fiber to connect individual houses and businesses to the network for broadband services up to gigabit speed.
HALNy HL-4GXV-F provides one GPON port (SC/APC type), 4-Gigabit Ethernet ports, 2 Dual-Band (2.4G and 5G) AX1800 WiFi 6 Wireless interface with four internal antennas, 1-Voice FXS port. This gives possibility to support full triple play services for high speed Internet access, IPTV and voice. The network interface is compliant to ITU-T G.984.5 to provide 2.5 Gb/s downstream and 1.25 Gb/s upstream. LAN interface allow to provide Gigabit service.
All products within the GPON family comply with current ITU-T standards for gigabit passive optical networks (GPONs). The solution is designed to optimize the deployment and roll-out of the service provider. HL-4GXV-F design offer multi-interoperability with several OLT vendors. The ONT/ONU products are tested and have proven interoperability with most major GPON OLT Vendors.
Specifications are indicative, please confirm current configuration with our team.
