| Part Number | RMTL18-SMSM -2M |
|---|---|
| Product | Phase and Temperature Stable RF Cable, 2m, SMA Male to SMA Male |
| Cable Type | Radiocomm TestLink Cable |
| Cable Type | Phase Stable Jumper Cable |
| Frequency Range | DC – 18GHz |
| Length | 2 meters |
| Temperature Stability | 800ppm |
| Input VSWR | < 1.1:1@DC-3GHz, < 1.15:1@3-6GHz, < 1.2:1@6-18GHz |
| Phase Stability | DC-10Ghz +/-1.1° 10-18Ghz+/-2° |
| Shield Effectiveness | >-110dB |
| Amplitude Stability | DC-26Ghz +/-0.05dB |
| Connector | SMA Male to SMA Male |
| Application | Indoor/Outdoor (IP68) |
RMTL18-SMSM -2M
Radiocomm
Low PIM and Phase Stable Cables
Phase and Temperature Stable RF Cable, 2m, SMA Male to SMA Male (RMTL18-SMSM -2M)
